Mysher’s CT302C is a pluggable video camera specifically designed for meeting room displays. It comes with a 120° wide-angle lens, a 4-array noise reduction microphone, and a convenient Type-C connector design, allowing you to integrate this camera directly into an Interactive Flat-Panel Display (IFPD). Thanks to the ViiCam camera control software, it provides 4K@30fps video quality, H.265 compression, face tracking, and sound localization features to deliver an amazing video conferencing experience.





| Sensor Size | 1.28" |
|---|---|
| Pixle Size | 1.45x1.45um |
| Lens FOV | D120, H110, V70 ± 3° |
| Lens Size | M12 × P 0.5 |
| F/NO(INFINITE) | 1.8±5% |
| TTL | 23.5±0.2mm |
| Focus Distance | 2.26mm |
| Lens Focus | Fixed |
| Focus Range | 1m- 8m |
| Operating Voltage | 5V |
| Working Current | 5V/1A |
| Frequency | 50/60Hz |
| Interface | Type-C |
| Video compression | YUY2/MJPG/H2.64/H.265 |
| Support video resolution | MJPEG / H.264 / H.265 3840x2160 2560x1440 1920x1080 1280x720 1024x768 640x480 640x360 320x180 YUY2 1280x720 640x480 320x240 |
| Max. FPS | 3840x2160@30fps |
| Support Algorithms | Auto Framing Voice Tracking |
| Microphone | Built-in 4 Microphone array |
| Sensitivity | -26db FS ±1db |
| signal to noise ratio | 64.5dBA |
| AOP | 120dB SPL |
| Dimension | 55.5 x 168 x 44 mm (LxWxD) |
